of 562 results found
View:

Filters

S4-90M-R1B-3XKIT S4-90M-R1B-3XKIT
Tri-sector solution that includes 3 S4-90M-R1B-V1 antennas and a lightweight mounting kit to install them on a pipe
S4-90M-R1B-3XKIT
  • Product type: Beamforming antenna | Tri-sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 24
  • Rf connector quantity, high band: 24
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
S4-90M-R1B-3XKIT
  • Product type: Beamforming antenna | Tri-sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 24
  • Rf connector quantity, high band: 24
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
S4-90M-R1B-V1 S4-90M-R1B-V1
8-Port Beamforming Antenna, 3700-4200 MHz, 1x RET
S4-90M-R1B-V1
  • Product type: Beamforming antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
S4-90M-R1B-V1
  • Product type: Beamforming antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
S4-90T-F-V2 S4-90T-F-V2
8-port Planar Array Antenna, 3400–4200 MHz, 90° HPBW
S4-90T-F-V2
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
S4-90T-F-V2
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 90°
  • Length size: 0.7 m (2 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SBJAH4-1D65B-DL SBJAH4-1D65B-DL
12-port sector antenna, 2x 698–798, 2x 824-896 and 8x 1695–2360 MHz, 65° HPBW, 3x RET and low bands have diplexers
SBJAH4-1D65B-DL
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 12
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 4
SBJAH4-1D65B-DL
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 306 – 353 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 12
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 4
SBNHH-1D45B SBNHH-1D45B
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 45° HPBW, 3x RET
SBNHH-1D45B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 45°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D45B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 45°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D45C SBNHH-1D45C
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 45° HPBW, 3x RET
SBNHH-1D45C
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 45°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D45C
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 45°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65A SBNHH-1D65A
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 65° HPBW, 2x RET. Both high bands share the same electrical tilt.
SBNHH-1D65A
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65A
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65B SBNHH-1D65B
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 65° HPBW, 2x RET. Both high bands share the same electrical tilt.
SBNHH-1D65B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65C SBNHH-1D65C
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 65° HPBW, 2x RET. Both high bands share the same electrical tilt.
SBNHH-1D65C
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D65C
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D85A SBNHH-1D85A
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 85° HPBW, 3x RET
SBNHH-1D85A
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 90°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D85A
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 90°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D85B SBNHH-1D85B
6-port sector antenna, 2x 698–896 and 4x 1695–2360 MHz, 85° HPBW, 3x RET
SBNHH-1D85B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 90°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SBNHH-1D85B
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 90°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 201 – 305 mm
  • Rf connector interface: 7-16 DIN Female
  • Rf connector quantity, total: 6
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 2
SS-65M-M SS-65M-M
4-port sector antenna, 4x 3100-4200 MHz, 65°HPBW
SS-65M-M
  • Product type: Sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.9 m (3 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
SS-65M-M
  • Product type: Sector antenna
  • Operating frequency band range: 3100 – 5000 MHz
  • Horizontal beamwidth: 65°
  • Length size: 0.9 m (3 ft)
  • Width/diameter: ≤ 200 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 4
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 0
